Ford Focus C-Max Kuga ELV ESL Steering Column Lock Emulator

Electronic Steering Column Lock (ESCL) ELV ESL Emulator for FORD C1 Platform – FOCUS, C-MAX, KUGA, etc

LIN version (black connector), 2012 and up

For Focus C-Max Kuga Steering Lock Emulator
For Focus C-Max Kuga Steering Lock Emulator Overview:
The device emulates the Ford ESCL unit, compatible with Ford C1 platform cars (Focus mk2, C-MAX, etc) starting from 2012 and up.
The original SCL part number looks like AVON-3F880-Jx, the connector has 4 pins, and only 3 wires were used, the SCL connector color is BLACK!!!
In case you have a GREEN connector, you have older K-line architecture instead of LIN - this emulator is not compatible with K-line systems.
Be careful because both part numbers (for LIN and K) are printed on the SCL casing with a remark to plug color.
Plug and Play No Alignment Necessary

For Focus C-Max Kuga Steering Lock Emulator Light Behavior:

Led on Emulator:
Red SCL is in a locked state
GREEN SCL is in an unlocked state

For Focus C-Max Kuga Installation on Car:

• Stop the car.
• Plug the connector into the Socket.
• Note that the original SCL is powered only when there is a request for status or command for open or close.
• Emulator Successfully Installed.

Pinout:

• pin 1: Not used (no wire)
• pin 2: +PWR (switched)
• pin 3: GND.
• pin 4: LIN
