XTOOL X100PAD Elite 2 — Professional Key Programmer & Diagnostic Tablet
Promotion not applicable outside the Middle East and Africa.
| CONDITION | new |
|---|---|
| Weight | 4 kg |
| CONDITION | new |
|---|
| Weight | 4 kg |
|---|
XTOOL X100PAD Elite 2 (2026) — Professional Key Programmer & Diagnostic Tablet
The XTOOL X100PAD Elite 2 (2026) is a professional-grade tablet built for automotive locksmiths and workshop technicians who need key programming and full-system diagnostics in a single device. It handles both add key and all keys lost jobs, reads and writes immobilizer data, retrieves PIN codes, and registers replacement ECU, BCM and dashboard modules — then clears the fault codes left behind once the job is finished.
The 2026 release ships with the KC100 key programmer, an EEPROM adapter and PCBA, and a wireless VCI box. Support for CAN FD and DoIP plus an FCA SGW licence means late-model gateway-protected vehicles are covered out of the box. Every unit includes 2 years of free software updates and a 2-year warranty.
Key Benefits at a Glance
- Add key & all keys lost — complete both scenarios on supported makes without a second tool.
- Immobilizer read/write — read and modify immo data and retrieve PIN codes where supported.
- Module programming — program and register replacement ECU, BCM and instrument cluster units.
- Post-programming diagnostics — full-system scan and fault code clearing after key or module work.
- 40+ special functions — oil reset, EPB, SAS, TPMS, DPF, throttle, injector coding and more.
- Gateway ready — FCA SGW licence for 2018 and newer Chrysler, Dodge, Jeep and RAM vehicles.
- Modern protocols — CAN FD and DoIP for current-generation vehicle architectures.
- Built for the workshop — rugged 8" tablet, 5000 mAh battery, Wi-Fi 2.4/5 GHz and BLE 5.0.
Technical Specifications
| Processor | Quad-core 1.5 GHz |
|---|---|
| Operating System | Android 10 |
| Display | 8" touchscreen, 1024 × 768 |
| Rear Camera | 8 MP |
| Connectivity | USB Type-C |
| Battery | 5000 mAh, 7.3 V |
| Wi-Fi | 2.4 GHz / 5 GHz |
| Bluetooth | BLE 5.0 |
| Working Temperature | 0 °C to 40 °C |
| Storage Temperature | -10 °C to 50 °C |
| Working Voltage | 6.1 – 8.3 V |
| Vehicle Voltage | 9 – 36 V |
| Communication | Wi-Fi, USB |
| Supported Protocols | CAN FD, DoIP |
| FCA SGW Licence | Included (2018 and later) |
| Free Updates | 2 years |
| Warranty | 2 years |
What's in the Box
Main Units
- X100PAD Elite 2 tablet
- VCI box
- KC100 key programmer
- EEPROM PCBA
- EEPROM adapter
Cables & Adapters
- DB15 main cable
- Type-C to Type-B cable
- Type-C to Type-C charging cable
- Micro USB to Type A/C adapter (for KC100)
- Power supply charger adapter — EU / UK / US
- DC power cable — EU / US
- DC power charger
Test Connectors
- OBD-II 16-pin connector
Accessories & Documentation
- Tool case
- Colour carton
- Quick start guide
- Packing list
- Certificate of quality
Special Functions
The X100PAD Elite 2 covers more than 40 service and reset routines across engine, transmission, chassis and body systems:
- EEPROM read/write
- ADAS calibration
- Instrument cluster
- Odometer read
- VIN write
- ECU configuration
- Control unit reset
- Oil service reset
- Transmission oil reset
- Gearbox adaptation
- Clutch adaption
- Throttle body relearn
- Injector coding
- Power balance
- Camshaft sensor learning
- Crank sensor relearn
- DPF regeneration
- GPF regeneration
- EGR relearn
- NOx reset
- AdBlue reset
- A/F reset
- VGT relearn
- Electronic water pump activation
- Start-stop reset
- BMS / battery reset
- HV battery service
- EPB (electronic parking brake)
- ABS bleeding
- SAS (steering angle sensor)
- Suspension calibration
- Airbag reset / SRS
- TPMS reset (AU, EU, JP, KR, US)
- Tire size setting
- Speed limit setting
- A/C relearn
- FRM reset
- Headlight adjustment
- Rain / light sensor
- Seat calibration
- Sunroof initialisation
- Window initialisation
- Transport mode
- Language change
Immobilizer & Key Programming Coverage
European
Alfa Romeo, Audi, Bentley, BMW, Citroën, Ferrari, Fiat, Jaguar, Lancia, Land Rover, Maserati, Mercedes-Benz, MG, Opel, Peugeot, Porsche, Renault, Rolls-Royce, Saab, SEAT, Škoda, Smart, Volvo, VW
American
Acura, Chrysler, Dodge, Ford, GM, Jeep, Lincoln, Mercury
Asian
Daihatsu, Genesis, Holden, Honda, Hyundai, Infiniti, Isuzu, Kia, Lexus, Mazda, Mitsubishi, Nissan, Perodua, Proton, SsangYong, Subaru, Suzuki, Toyota
Chinese & Other Makes
BAIC, Baojun, Besturn, Borgward, Brilliance, BYD, Changan, Changfeng, Changhe, Chery, Denza, DF Fengguang, DF Fengshen, DF Fengxing, FAW JB, Foton, Geely, Great Wall, Hafei, HN Mazda, Hawtai, Hongqi, Iveco, JAC, JMC, Lada, Leapmotor, Lifan, Li Xiang, Lufeng, Luxgen, Lynk & Co, Maxus, Neta, Roewe, Seres, Southeast, Trumpchi, ZZ Nissan — plus KC501 library support.
Diagnostic Vehicle Coverage
Full-system diagnostics across a wide manufacturer list, including dedicated menus for BMW extended capabilities, VW Expert, Nissan PIN data, Nissan GT-R, Mercedes-Benz Transporter and regional Ford variants (USA, EUR, AUS):
Abarth, Acura, Alfa Romeo, Aston Martin, Audi, Bentley, BMW, Bugatti, Buick, BYD, Cadillac, Chery, Chevrolet, Chrysler, Citroën, CMC, CVVW, Dacia, Daewoo, Daihatsu, Dodge, Ferrari, Fiat, Ford (USA / EUR / AUS), GAZ, Geely, Geely Monjaro, GM, GMC, GWM, Holden, Honda, Hummer, Hyundai, Hyundai CV, Infiniti, Isuzu, JAC, Jaguar, Jeep, Kia, Lamborghini, Lancia, Land Rover, Lexus, Lifan, Lincoln, Luxgen, Maserati, Maybach, Mazda, Mercedes-Benz, MG, Mini, Mitsubishi, Nissan, Opel, Perodua, Peugeot, Polestar, Pontiac, Porsche, Proton, Renault, Renault Samsung, Roewe, Rolls-Royce, Saab, Saturn, Scion, SEAT, Škoda, Smart, SsangYong, Subaru, Supra, Suzuki, Toyota, Vauxhall, Volvo, VW — plus generic OBD-II.
