obdstar P001 multi functional programmer device
obdstar P001 multi functional programmer device
obdstar P001 multi functional programmer device

OBDStar P001 Multi Functional Programmer Device

235 $ 235 €


TL34125
Sorry, this product is currently out of stock.
ITEM CODETL34125
MANUFACTUREROBDStar
TYPEKey Programming Tools
PART NUMBERP001
COLORBlack


Product Description

OBDSTAR P001 programmer integrated with EEPROM adapter, RFID adapter, and Key Renew adapter, which is compatible with simulated smart keys to realize the Toyota all lost and program keys for Renault.

OBDSTAR P001 Programmer RFID & Renew Key & EEPROM Functions 3 in 1 Work with OBDSTAR X300 DP Master

OBDSTAR P001 Programmer for X300 DP/Key Master DP = EEPROM adapter, RFID adapter, and Key Renew adapter 3-in-1

OBDSTAR P001 Programmer Features:

On the basis of original adapter features, the P001 programmer, integrated with the EEPROM adapter, RFID adapter, and Key Renew adapter, is a multifunctional programmer.
OBDSTAR P001 not only allows auto technicians
to reduce cumbersome procedures but also is compatible with simulated smart keys to realize the Toyota all lost.
OBDSTAR P001 can program keys for
Renault Talisman/Megane IV/Scenic IV/Espace V used with OBDSTAR Converter.

P001 programmer uses dual coils with stronger signal, supporting a wider range than RFID. It is also required in recent model upgrades, as follow:

Ferrari 458/F12/F149;
Maserati mechanical key;
Fiat 500/Viaggio/Palio/Siena/Boyue/Pailang/Ottimo, etc.
Iveco;
Alfa Romeo;
Volkswagen MQB;
Toyota  simulated cards;
BMW;
Porsche;

Note: OBDSTAR P001 Programmer only works with OBDSTAR X300 DP

P001 Programmer Configurations

P001 programmer (full package):

P001 programmer unit+ C001 circuit board + C002 circuit board + W001 data cable + W002 data cable + W003 data cable + Toyota simulated smart key (free);

Remark: Customers who purchase P001 programmer can obtain a Toyota simulated smart key for free

P001 Programmer Accessories

Accessory 1: C001 circuit board

The C001 circuit board is compatible with old NO. 3 and 4 circuit boards, applying to EEPROM chip dismantling and reading, Tianjin FAW and VIZHI immobilizer coil initialization, and other functions.

p001-accessories-1
Accessory 2: C002 circuit board

The newly developed C002 circuit board is connected by W001, W002, or W003 without welding the chip.
p001-accessories-2
Accessory 3: W001 data cable

The W001 data cable can read or write data by linking the chip with a bonding wire
p001-accessories-3
Accessory 4: W002 data cable

The W002 data cable can read or write data by clamping the chip (SOP 8-pin) directly without welding EEPROM.
p001-accessories-4
Accessory 5: W003 data cable


The W003 data cable can read or write data by clamping the positive pole and negative pole with red and black clips and contacting the data interface with yellow and blue probes.


Wiring Instruction

To better understand the connection between the P001 programmer and its accessories, examples for W001 and W003 wiring instructions are as below. (During the actual operation process, there is a diagram of wiring inside the tablet)

Way1. W001 Connecting

p001-wiring-instruction-1

Way 2. W003 Connecting

p001-wiring-instruction-2

About Toyota simulated smart key

1.Why use a Toyota simulated smart key?

For the Toyota/Lexus 2007-2016 models, if all smart keys are lost, the instrument table must be removed and the ECU must be replaced. The cost is very high!
This Toyota simulated smart key can generate a Toyota key with our devices in the case of all keys lost, so the ignition switch can be turned on, and then a new smart key can be added and programmed with our devices.

2.What are the advantages of the Toyota simulated smart key?

Save costs;
Reusable.



3.Which type of smart keys can be simulated?
Simulated key 1 applies to the vehicle with 94/D4 type of smart key;
TOYOTA simulator card

×
