NXP Smart Key Adapter P/N: MCKB164 For Geely 2025 2027

MCKB164 NXP Smart Key Adapter for Geely Galaxy A7 / M9 2025–2027

The MCKB164 NXP Adapter is a universal NXP key programming adapter built for adding smart remotes to the latest Geely Galaxy A7 and M9 (2025–2027). It connects directly to the remote's NCF29xx board, letting you prepare a new key for vehicle addition quickly and safely, without opening the car's modules.

Key Features

• Fit for all NCF29xx chip remotes: designed for Geely smart keys using NXP NCF29xx chips with ID4A transponder.
• Key remote adding: prepares the remote board for adding a new key to the vehicle.
• Solder-free connection: spring-loaded contact pins and two locking clamps hold the PCB securely in place.
• Clear pinout: labeled VCC, MSDA, WAKE, GND and MSCL headers plus a multi-pin connector for easy wiring to your programmer.
• Stable and reliable: durable PCB build (164-V1.0) for safe, repeatable programming.

Technical Specifications

Part Number	MCKB164
Adapter Type	NXP Smart Key Adapter
Supported Chip	NXP NCF29xx / ID4A
Supported Remote FCC	6608272524W28, 6608272524B53
Remote Buttons	3 Buttons
Pinout	VCC, MSDA, WAKE, GND, MSCL
Board Version	164-V1.0
Condition	New
SKU	TL42306

Reference Car Models

• Geely Galaxy A7 2025–2027
• Geely Galaxy M9 2025–2027

How It Works

1. Remove the PCB from the Geely smart key shell.
2. Place the board on the MCKB164 adapter and lock it with the two clamps so the contact pins align with the test points.
3. Connect the adapter to your key programming tool using the labeled pins or connector.
4. Run the remote preparation/adding function in your programming software, then add the key to the vehicle.

Package Includes

• 1 × MCKB164 NXP Smart Key Adapter

Note: The key programmer and the remote key are not included. Please make sure your programming device supports this adapter before ordering.
