NXP Smart Key Adapter P/N: MCKB029 For Hyundai 2015 2017

NXP Smart Key Adapter P/N: MCKB029 For Hyundai 2015 2017

The MCKB029 solder-free adapter is a universal NXP key programming work board built for Hyundai 2015-2017 smart remotes. It connects directly to the key PCB so you can add remotes and perform chip read/write operations without soldering or damaging the original board.

Key Features

• Fits all NCF29xx chip remotes — broad coverage in one adapter
• 100% solder-free operation, no heat applied to the key PCB
• Spring-loaded clamps hold the smart key board tight for stable contact
• Gold-plated pogo pins deliver reliable, low-resistance signal transfer
• Labeled pinout: MSCL, GND, WAKE, MSDA, VCC, plus SDA, SDA-1, SCL, SCL-1, VCC and GND test points
• Includes a probe wire and multi-pin connector socket for tool cables
• Board version 29-XD-V1.0, supplied in a protective storage case

Compatibility

Designed for Hyundai 2015 to 2017 smart keys using NXP NCF29xx chipsets. Works with mainstream key programmers that support NXP smart key read and write, including KYDZ, KD (Keydiy), VVDI and similar tools.

Package Includes

• 1 x MCKB029 Solder-Free NXP Key Adapter For Hyundai 2015-2017
