TL42139
Specifications
| CONDITION | new |
|---|---|
| Weight | 0.1 kg |
| CONDITION | new |
|---|
| Weight | 0.1 kg |
|---|
Compatibility1 Vehicles
| Brand | Model | Year (From–To) |
|---|---|---|
| Hyundai | Genesis | 2022–2024 |
NXP Smart Key Adapter P/N: MCKB054 For Hyundai Genesis 2022 2024
The MCKB054 Universal NXP Key Programmer Adapter is a solderless work board designed for Hyundai Genesis 2022–2024 smart remotes built around NXP NCF29xx chips. It gives automotive locksmiths a stable, repeatable connection to the remote PCB so key and remote adding can be completed quickly, without soldering or damaging the board.
Key Features
- Covers Genesis 2022–2024 remotes — the printed board outline matches the rectangular Genesis smart key PCB used on these model years.
- Fits all NCF29xx chip remotes — broad support across the NXP NCF29xx smart key chip series.
- Key & remote adding — supports adding new remotes to compatible Genesis vehicles.
- Solder-free operation — two spring-loaded clamp arms press the PCB onto gold-plated contact pads, so nothing needs to be soldered.
- Clearly labeled pinout — MSCL, GND, WAKE, MSDA and VCC are printed along the lower edge for fast, error-free wiring.
- Includes WAKE probe wire — the pre-attached red probe lead lets you reach the wake point when the board requires it.
- Stable and reliable — a rigid base plate and screw-mounted clamps keep contact pressure steady throughout the session.
Board Layout
The adapter is marked 54-V1.0 and carries on-board test points labeled VCC, GND, SDA, SCL, and WAKE, plus a 5-pin header along the lower edge for the connection cable. A central cutout exposes the target chip area, and the two adjustable clamp arms secure the remote PCB firmly at opposite corners.
Specifications
| Part Number | MCKB054 |
| Board Version | 54-V1.0 |
| Vehicle Brand | Hyundai |
| Model | Genesis |
| Model Years | 2022 – 2024 |
| Chip Support | NXP NCF29xx series |
| Function | Key/remote adding |
| Connection Type | Solderless clamp with 5-pin header |
| Labeled Pins | MSCL, GND, WAKE, MSDA, VCC |
| Test Points | VCC, GND, SDA, SCL, WAKE |
| Condition | New |
| Weight | 0.1 KG |
Package Includes
- 1 x MCKB054 NXP Smart Key Adapter Board (54-V1.0)
- WAKE probe wire (pre-attached)
- 1 x Protective storage case
