VN021 - MQB Immo Data extraction from RH850 dump

RequirementsAMSI18
The VN021 license allows extracting the Immobilizer data from dump of RH850 processors, used in VAG MQB dashboards with Megamos-AES keys. Upon reading the RH850 processor using the ABRITES Programmer, CS, MAC, Keys, and PowerClass information is visualised in the software.
This data can then be used for adding a spare key to the vehicle. It can also be used to exchange the instrument cluster, which requires extracting Immo data from both the replacement module, and the donor one.

Functionalities:

Reading Immo data from dump of RH850 processors in VAG MQB dashboards
Spare key addition
Instrument cluster exchange

Supported vehicles:

VAG vehicles with the following dashboards

VDO MQB Analogue RH850
VDO MQB Virtual Cockpit RH850

AVDI with active AMS and the ZN085 ABRITES RH850/V850 Programmer are required to use this license.
This license will be enriched with additional functionalities, details will be announced soo
