TL34454
FREE SHIPPING
Autel XP400 PRO Key Programming
FREE SHIPPING
Autel XP400 PRO Key Programming
Autel XP400 PRO Key Programming

Autel XP400 PRO Key Programming and Chip Programmer autel key fob programming Compatible for Autel IM508 & IM608 & IM608 Pro & IM100 & IM600

600 $ 600 €


TL34454
Sorry, this product is currently out of stock.
ITEM CODE TL34454
MANUFACTURER Autel
TYPE Key Programming Tool
PART NUMBER XP400
COLOR Blue

Autel XP400Pro Adapter Autel Key Programmer Working with Autel IM508, Autel IM608, Autel IM608 Pro, Upgraded Version of XP400

The XP400Pro key and chip programmer is from Autel products, compatible with IM508 and IM608, and reads/writes and learns car keys.
The XP400Pro enables the programming of IR keys for Mercedes vehicles and IC Chip on late Hyundai Kia models.
XP400 also performs EEPROM data functions needed for European vehicles.
XP400Pro supports reading/writing data for more than 3000 kinds of chips (including EEPROM, Engine ECU, MCU, and IMMO ECU).

The XP400Pro enables the programming of IR keys
Notes:
  1. Upgraded from XP400, no costly mistake to burn it by not connecting to cars anymore.
  2. IMMO extended functions in BMW, BENZ, Audi, etc.

Upgraded from XP400 , IMMO extended
Extra Note: The functions are not universally compatible, please send us a VIN for verification before purchasing.

Autel XP400PRO Specifications:

* Operating temperature: -10 ~ 70 (14℉ ~ 158℉)
* Storage temperature: -20°C ~ 85°C (-4°C ~ 185°C)
* Port type: B-USB, DB26, DC12
* Input voltage: 5VDC, 12VDC
* Operating current: <500mA
* Maximum consumption: 2.5W
* Machine Dimensions: (L*W*H) 168mm*98mm*30mm
* Net Weight: 520g

Operating temperature, Storage temperature

What can XP400 PRO Autel Do?

Extended EEPROM functionality for more access to components
More than 170 kinds of odometer component reading functions
180+ kinds of immobilizer ECU components
40+ types of engine components ECU
2000+ MCU Component Types
440+ types of EEPROM components
Compatible with IM508, IM608, and the latest IM608 Pro
Note1: The XP400 Pro has been updated, and the XP400 issue has been fixed that it can't connect to the vehicle's OBD connector which may cause the XP400 mainboard to fatigue.
Please always note that XP400 Pro can only perform IMMO functions when connected to the Autel scanner tool and adapters such as APA104, APA105, etc.
Note2: The functions are not universally compatible, please send us a VIN for verification before purchasing.

cost-effective combination for you to maximize the IMMO functions

What Is XP400 PRO Compatible With?

The XP400 Pro has been extended IMMO functionalities on BMW, BENZ, Audi, etc.,
Designed to work with IM508, IM608, and IM608 Pro to perform various IMMO Key programs, key chip programming functions, MCU writing, reading, etc.
Auto Detect Make, Model, Year, and System.
Read PIN (All Key Lost), Key Learning, IMMO ECU Reset/Adaption, IMMO ECU Refresh / Key Coding, Remote Learning
For AUDI Q5/ A4/A5 2015-2017 Key Learning
For VW MQB Key Learning
For BMW FEM/BDC Key Learning and Adaption
For BMW CAS4 Key Learning and Adaption
For Mercedes key programmer
For 2015-2018 Land Rover & Jaguar write key via dump
For Volvo Smart Key Learning/ knob-style smart key, etc.

NOTE: IM608+ XP400 Pro is a very powerful tool combination to satisfy your needs for IMMO key programming.
However, if with a limited budget, IM508+ XP400 Pro is a cost-effective combination for you to maximize the IMMO functions.
NOTE: The functions are not universally compatible, please send VIN to check before purchase.

What Is XP400 PRO INCompatibile With?

Autel XP400 Pro works with Autel IM508 for more than 80 American, Asian and European makes and models, especially XP400 Pro extended functions in BMW, BENZ, Audi, etc.
For Benz: One-Click Autel Key Programming via OBD, IMMO 3rd Generation/K-Line Add Key, All Keys Lost.
For BMW: IMMO intelligent programming (support EWS3/4, CAS 1/2/3/4, FEM/BDC), add key/all keys lost.
For Volkswagen/Audi: One-click online programming, add key/all key lost via OBD for 2013-2020 models.
For GM: Read IMMO password, add key/all keys lost until 2020.
For Ford: Add key / all keys lost (no PIN needed) until 2020.
For Mazda: add key/all keys lost (no PIN needed) until 2020 FCA, read IMMO password, add key/all keys lost until 2020.
For Renault: Add key / Lost all keys (no PIN needed) until 2020.
For Land Rover / Jaguar: add key / all keys missing until 2019.
For Volvo: Semi-Smart Key Learning via OBD up to 2018, Smart/Blade/Fobik Key Learning via Dump, etc.
Note: Jobs are not public, send VIN for verification.

XP400Pro adds support for the following chips:

EEPROM - >> AMD - >> AM29FXXX series chip
EEPROM - >> FUJITSU - >> MB29FXXX series chip
EEPROM - >> ST - >> M29FXXX series chip
Engine control unit - >> ST - >> M29FXXX series chip
IMMO - >> BENZ - >> ESL_W209_W906 (Motorola) Read/Write/Erase function
IMMO - >> BMW - >> Read / write function of the EWS3 unit
REMOTE_RENEW (Renewal Key) - >> NEC - >> Read/Write/Erase V51 and V5 chip

Autel IMKPA key programming accessory adapter kit

XP400 Pro adds support for the following IMKPA Extensions (You need to purchase IMKPA Extensions separately)

APB113 PCF79XX Adapter Board
APB114 EWS3 Adapter Board
APB115 NEC Adapter Board
APB118 NEC ELV Adapter Board
APB119 TB28FXXX Adapter Board
APB120 TMS370 Adapter Board
APB121 AM29FXXX Adapter Board
APB122 AM29FXXX Adapter Board 1
APB123 AM29FXXX 2 . Adapter Board
APB126 M35080/D80 . Adapter Board
APB127 MC68HC0 (7) Adapter Board 05BXX
APB128 MC68HC05X32 Adapter Board

EEPROM , MCU , Engine ECU
Comparison of XP400, XP400 Pro, and VVDI Pro
FeaturesXP400XP400PROVVDIPROG
EEPROM read/ write330 chip types445 different chip types newly added support (AM29FXXX seriesMB29FXXX series)429 different chip types
MCU read/ write1541 chip types2067 chip types1758 different chip types
Engine ECU read/ write40 chip types41 chip types add write support for SIMTEC76(AM29F800BB)_WRITEEngin ECU read (74 types)
Immobilizer ECU read/ write168 chip types181 chip types171 chip types
Odometer read/ writeread odometer module 9 typesread odometer module 171 types (update in July)read odometer module 171 types
Airbag read/ writeread airbag module 5 typesread airbag module 5 typesread airbag module 54 types
Frequency detection315/ 433/ 868MHz315/ 433/ 868MHzN/A
Key read/ writesupportsupportN/A
Unlock keyN/Asupport 11 key types (Audi/ BMW)6 key types
Write key via dumpMitsubishi, Suzuki, fiat, landrover, JaguarMitsubishi, Suzuki, fiat, landrover, JaguarSupport 40+ vehicle makers
Easy to use/ stability1. menus are too valuable and can’t select intuitively
2. with high-definition wiring diagrams (not sufficiently covered)
1. The stability of key read/ write chip read/ write, and IR key read/ write is greatly enhanced.
2. menus are too vague and can’t select intuitively
3. with high-definition wiring diagrams (not sufficiently covered)
1. menus are clear and easy to use
2. with high-definition wiring diagrams (sufficiently covered)
3. high stability of chip read/ write

XP400 PRO PACKAGE INCLUDING:

  • 1pc x XP400 PRO Autel Main Unite
  • 1pc x APB129–EEPROM Adapter
  • 1pc x APA002–EEPROM Socket
  • 1pc x APB125–Mercedes Infrared Collector
  • 1pc x APB103–MCU_PLCC52 Adapter
  • 1pc x APB104–MCU_FQFP64 Adapter
  • 1pc x APB105–MCU_FQFP80 Adapter
  • 1pc x APB106–MCU_FQFP112 Adapter
  • 1pc x APB107–MCU_FQFP144 Adapter
  • 1pc x APB108–MCU_FQFP176 Adapter
  • 1pc x APB109–MCU_FQFP32 Adapter
  • 1pc x APB110–MCU_FQFP48 Adapter
  • 1pc x APB111–MCU_SO28 Adapter
  • 1pc x APA101–Spare Signal Cable
  • 1pc x APC101–USB Cable (Standard USB–Type B USB)
  • 1pc x APA103–EEPROM Clamp
  • 1pc x APA107–ECU Cable
  • 1pc x APA108–MCU Cable
  • 1pc x APA109–MC9S12 Cable
  • 1pc x Dupont Line
XP400 Pro Main Unite and accessory

User Manuals Download

XP400 Pro Manual
XP400 Pro Flyer
×
